Neues 4X4 ISUZU Automatic transmission roof lift RV configuration tabl Wohnmobil

Chengli Group is the largest special-purpose vehicle manufacturer in China. We can customize ISUZU, FOTON, HOWO, SINO, JAC, SHACMAN, DONGFENG, JMC and other brand trucks according to your needs.

4X4 ISUZU Automatic transmission roof lift RV configuration table
Bottom plate configuration


body of car
parameter Announcement number CLW5080XLJ6ASX Cylinder type QL1111CHKAY
Car color ◎ outline dimension (mm) 5998*2400*3450
curb weight (kg) 7392 gross mass (kg) 7800
wheel base (mm) 3815 fuel tank capacity 100L
Seat configuration Airbag shock absorber seat

dynamical system engine type 4HK1-TCG61 displacement (ML) 5.2
power (KW) 139 Fuel type diesel oil
Fuel supply type high pressure common rail torsion (N.M) 510
effluent standard Euro IV horsepower 190
transmission
system gear-box 6AT Drive form 4x4
Front suspension Front transverse leaf spring Posterior suspension Steel spring non-independent suspension
Drive mode Four-wheel drive by time tyre size 8.25R20

safe
configure Open and close the electric window of the driver and passenger have Vehicle Stability System (ESP) have
Central control door lock + remote key have Air conditioning in the car have

Upper assembly configuration
surface Hardcore High strength aluminum alloy body Steel structure carriages/safely and securely fastened Electric three-stage pedals
Vroom dedicated passenger door + screen door Special window and hatch for caravans External 220V mains interface Outdoor lighting
External water inlet Indoor ladder 4m sunshade
pilothouse Double bed with headboard Privacy curtain The original seat cushion of the main and passenger seats is soft Reversing image all-in-one machine
Smart keys LED headlights/day running lights/ground lights Multi-function steering wheel
Home furnishings E0 grade environmental protection RV special board Furniture color: (multiple colors are available) Waterproof and wear-resistant floor leather Vehicle insulation sound insulation noise reduction treatment
Twin bed / bunk bed / double bed Under-bed storage compartment mattress Swarve window (mosquito screen, privacy curtain)
Two / pair of card seats Elevated dining table / disassembled dining table Shelving cabinets, storage cabinets, shoe cabinets Privacy curtains in living area
kitchen Induction cookers (AC220V) RV refrigerator 130L A covered sink for washing vegetables Storage drawer
bathroom The bathroom assembly Stainless steel pool in the toilet Toilet exhaust fan Sanitary lighting
Bathroom sink toilet glass Pull-out dual showerhead Shelves + towel rods + shower brackets
Anti-slip waterproof floor 20L electric water heater Electrically powered flush toilets
circuitry Vehicle cable system laying Warm color LED ambient light Lighting, spotlights, light strips reading lights
32A leakage protection device Low voltage protector Dual battery isolator Overload control protector
Power switch assembly Luxury master control switch panel 220V/12V AC and DC power socket USB charging port
Voltmeter, water level meter, coulometer Nine-square ceiling light 32-inch milsi LCD network TV Guns and sound systems
24V 6KW sine wave charging inverter Lithium iron phosphate battery (24V400AH) Hitachi 2-drive zoned air conditioning microwave oven
900W solar panels
waterway Vehicle inlet and drainage system assembly PPR waterpipe Diaphragm pump (12V) blow-down valve
Stainless steel water tank 180L Stainless steel sewage tank 80L Water tank insulation treatment External shower
else External cable 10 meters driver's tool fire extinguisher smoke alarm
Safety hammer
The roof is exposed Roof terrace bowl fitting mechanism (including hydraulic system
Lighting legs) + second floor environment sofa with cold
Air conditioning in warm zones
